Delphi GT150 Series Wire Seal for Delphi Electrical Connectors 15366021 15419715 15423278

Product Details:

OEM PN：15366021

ID NO： W059

Material：Silicone

Seal Type：Single Wire Seal (SWS)

Inquire Now Download

Next Product

Product Description

Product Name	Single Wire Seal (SWS)
Original Number	15366021
Material	Silicone
Size	L: 6±0.2 ID: 0.95±0.2 OD: 4.5±0.2
Color	White
Hardness	40±2
Operating Temperature range	-40℃~125℃
Function	Waterproof sealing for Delphi Automotive connector and Wiring Harness
Certification	TUV,TS16949,ISO14001 system and RoHS.
MOQ	Small order can be accepted.
Payment term	30% deposit in advance,70% before shipment,100% TT in advance
Delivery Time	Enough stock and strong production capacity ensure timely delivery.
Packaging	1000,2000,5000,10000PCS per bag with label,export standard carton.
Design ability	We can supply sample, OEM&ODM is welcome. Customized drawing with Decal, Frosted, Print are available as request

CUSTOM SERVICE

1. A wire range of standard colors--Pantone
Silicone wiring harness seals from MIN TO MAX are available in a wide range of colors (Solid or Translucent) to match application requirements.

2. The perfect match of durometer, shape and colors.
Available in a durometer range of 20-80 Shore A, the silicone wiring harness seal can be made with the hardness that best matches the requirements of plastic or metal housing applications. MIN TO MAX can produce the most complex sealing shapes, as well as color match silicone materials in solid or translucent colors.

3. Advanced manufacturing processes for cost-effective solutions.
MIN TO MAX's LIM (liquid injection molding) systems provide consistent, high-quality and cost-effective connector seals virtually flash-free. We utilize the latest compression and transfer molding technologies to meet your requirements.

4. Fast prototypes and design engineering assistance.
In-house tooling capabilities and an experienced design engineering staff allow MIN TO MAX to deliver rubber seal prototypes fast. Our engineers have expertise in polymer technology with a paticular emphasis on slicone--as well as plastics , metals and other materials to assis you in creating the right housing seal solution for your application.

5. Seal it right from MIN TO MAX.
Allowing for direct communication with a knowledgeable seals team and design engineers in one place, MIN TO MAX has the capatilities to meet all your seal requirements.

COMMON NAME	SILICONE	FPM	NBR	IR	IIR	CR	NR	EPDM	ECO
SHORE A RANGE	30-80	50-90	30-90	40-90	30-80	20-90	20-90	30-90	40-90
